Simpson Dura Vent Stove Pipe

DuraVent DVL Stove Pipe - How to Install DVL Double Wall Stove Pipe

Click Here http://www.northlineexpress.com/ to see all of our Chimney Pipe. Joe shows you how to install DuraTech DVL Double Wall Stove Pipe. Insert the adapter or Connector section of pipe into the installed ceiling support box. Install it so the seams are in the back. Insert inner sleeve into outer sleeve (if applicable). Slide Ring over the bottom of the adapter. Screw the Trim Plate to the support box or wall thimble. Slip top piece of DVL pipe over adapter and screw together, you may need to pre-drill the hole in through the piece of pipe. Next you will need to install the stove top adapter into the collar on the stove. Place adapter on top of the collar and gently slide down on...

DuraVent DuraBlack Stove Pipe - How to Install DuraBlack Single Wall Stove Pipe

Click Here http://tinyurl.com/olptsz5 to see all of our Chimney Pipe. Joe shows you how to install DuraTech DuraBlack Stove Pipe. Insert the adapter or Connector section of pipe into the installed ceiling support box. Install it so the seams are in the back. For the stove pipe connector with a trim ring, you will insert the pipe into the support box then slide the trim collar on and slide up to the support box, until it is next to the pipe bead. Using the four pre-drilled holes in the trim collar as a guide, drill 1/8" diameter holes in the support box, and attach using the sheet metal screws provided. Next you will need to install the stove top adapter into the collar on the stove....
